Specifications:
- Two parallel tremolo lines which speed can be controlled individually with SPEED 1 and SPEED 2 knob.
- tremolo line speeds can be synched by turning SPEED 2 fully clockwise.
- Tremolo line can be switched off by turning SPEED 1 or SPEED 2 fully counterclockwise.
- Two tremolo modes
- Amplitude Modulation (AM): Regular volume modulation
- Harmonic Modulation (HM): Bass and treble frequencies are modulated in amplitude separately. SPEED 1 controls the speed of the bass frequency modulation, SPEED 2 of the treble modulation.
- 3 modulation waveforms
- Square
- Sine
- Triangle
- DEPTH controls the intensity of both tremolo lines.
- VOLUME sets the overall output volume of the effect
- MIX blends between the dry unaffected and the modulated signal. This is especially useful when wanting to tame the harmonic tremolo effect.
- Expression pedal input for controlling SPEED 1 or DEPTH (can be set using EXP toggle switch)
- Relay-based true bypass with momentary hold function. External bypass port allows connecting the footswitches of different Iceberg Effects pedals together
- Left footswitch overwrites the SPEED 1, Depth or SPEED 2 knob (depending on the position of the ALT toggle switch) with the level set by the ALT knob. Hold the left footswitch to momentarily engage/disengage the ALT setting
- Top mounted jacks
- 1590BB2 enclosure 120 x 94 x 39 mm
- Center negative power supply
- Current draw 100 mA
