Reflect Delay V2

A modulated tape delay that can produce short slap back type delays and longer ambient haunting delays. Now with added INFINITE momentary switch that swells the REPEATS(This is like turning the REPEATS knob all the way clockwise) and a RATE LED indicator. Each pedal is individually acid etched so no two pedals are alike visually!



Controls:

TIME- Turning this control counter clockwise creates a short slap back type delay. When turned clockwise, the delay becomes a haunting ambient echo. Delay times range from 30ms - 600ms

REPEATS- This allows the delay signal to regenerate on top of itself. Turning this control clockwise will start to increase the regenerating signal until it begins to self-oscillate. Turn it fully clockwise to make the signal repeat infinitely.

MIX- This controls the amount of delay effect mixed into the output signal, turn clockwise for a full wet signal.

DEPTH- This controls the amount of LFO modulation added into the wet delay signal.

SHAPE- Effects the waveform shape of the LFO modulation. When turned fully counter clockwise, the waveform is a triangle wave and gradually changes to a square waveform as you turn it clockwise.

RATE- This controls the speed of the modulation effect. Turn clockwise for a faster rate of speed, counter clockwise for a slower rate.

INFINITE FOOTWITCH- This turns the repeats all the way up, creating a cascading swell.

USE A 9V DC 2.1mm CENTER NEGATIVE POWER SUPPLY
